Overview
Specimen Track HW Enterprise WIFI Router is designed for enterprise branch offices and small businesses, delivering a comprehensive set of services, including routing, switching, voice, security, and wireless access.
Technical Specifications
| Processor | Dual-core, 533 MHz |
| Memory | 512 MB |
| Flash | 512 MB |
| Micro SD Card (SD1 By Default) | None |
| Hard Disk | Not supported |
| Maximum Power Consumption | 16.1 W |
| Management Interfaces | 1 (R J45) |
| CON/AUX Interfaces | 1 (R J45) |
| USB 2.0 | 1 |
| Service Interfaces (Standard Configuration) | WAN interface: one ADSL-B/J interface
LAN interfaces: four FE electrical interfaces, in which the FE0 LAN interface can be switched to a WAN interface. |
| Extended Slots | Not supported |
| Operating Temperature | 32 °F to 113 °F (0 °C to 45 °C)
NOTE: When the altitude is between 1.12 mi (1800 m) and 3.11 mi (5000 m), the operating temperature reduces by 33.8°F (1 °C) every time the altitude increases 0.13 mi (220 m) |
| Storage Temperature | -40 °F to 158 °F (40 °C to 70 °C) |
| Operating Relative Humidity | 5 % to 95 %, non-condensing |
| Operating Altitude | 3.11 mi (< 5000 m) |
| Dimensions (H x W x D) | Without rack-mounting bracket installed: 1.73 in x 11.81 in x 8.52 in (44.0 mm x 300.0 mm x 216.4 mm)
With rack-mounting brackets installed: 1.73 in x 19.00 in x 8.52 in (44.0 mm x 482.6 mm x 216.4 mm) |
| Weight | 6.17 lb (2.8 kg) |
