Overview
Specimen Track Indoor WIFI SIM Router stands out by integrating routing, switching, wireless, and security functions. In addition to offering conventional routing gateway functions, it provides powerful application expansion capabilities, for example, functioning as an IoT communication gateway to aggregate data. This makes it ideal for wide use in diverse industries.
Technical Specifications
| Processor | Dual-core, 1 GHz |
| Memory | 512 MB |
| Flash | 512 MB |
| Rated Input Voltage (DC) | 12 V |
| Maximum Input Voltage (DC) | 10.8 V to 13.2 V |
| Maximum Output Current | 1 A |
| RPS Power Supply | Not supported |
| PoE Power Supply | Supported |
| Maximum Power Consumption | 12 W |
| Management Interfaces | 1 (RJ 45) |
| CON Or RS232 Interface | 1 (RJ 45) |
| USB 2.0 Interfaces | 1 |
| Service Interfaces (Standard Configuration) | WAN interfaces: one GE electrical interface, one VDSL interface and two LTE antenna interfaces LAN interfaces: four GE electrical interfaces |
| Operating Temperature | PoE power supply used: 32 °F to 104 °F (0 °C to 40 °C) PoE power supply not used: 77 °F to 140 °F (-25 °C to 60 °C) NOTE: When the altitude is between 1.12 mi (1800 m) and 3.11 mi (5000 m), the highest operating temperature reduces by 33.8 °F (1 °C) every time the altitude increases by 0.13 mi (220 m) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Operating Relative Humidity | 5 % to 95 %, non-condensing |
| Operating Altitude | 3.11 mi (< 5000 m) |
| Dimensions (H x W x D) | 7.48 in x 8.66 in x 1.73 in (19 cm x 22 cm x 4.4 cm) |
| Weight | 3.35 lb (1.52 kg) |
