Features
- 12-in-one function OTDR, VFL, OLS, Cable Test etc
- The 4.3-in (10.92 cm) full-view capacitive touch screen
- Cover plate type tempered glass panel
- Support horizontal version
- Perfect fusion of the two habits of user operations
- Support charging treasure charging,
- the international standards of test data with perfect simulation software
- Sink type light port design,
- Support U disk, SD card and Micro USB export data protection
- Any interface supports screen capture
Technical Specifications
| Testing Distance | 0.06 mi, 0.31 mi, 1.24 mi, 3.10 mi, 6.21 mi, 12.42 mi, 24.85 mi, 55.92 mi (100 m, 500 m, 2 km, 5 km, 10 km, 20 km, 40 km, 90 km) |
| Sampling Resolution | Minimum 0.65 ft (0.2 m) |
| Sampling Point | 64,000 |
| Linearity | ≤0.05 dB |
| scale Indication | X axis: 4 m/div to 70 m/div, Y axis: 0.09 dB/div to 5 dB/div |
| Loss Threshold | 0.01 dB |
| Loss Resolution | 0.001 dB |
| Distance Resolution | 0.01 m |
| Distance Accuracy | ± (1.64 ft (0.5 m) + Range × 3 × 10 – 5 + Sampling resolution) （Excluding refractive index error） |
| Display | 4.3-in (10.92 cm) capacitive touch screen with full viewing, TFT 800 pixels x 480 pixels resolution |
| Battery | 5200 mAh or 3.7 V, standby time > for 10 hrs |
| Power Adapter | Power supply AC or DC adapter, input 100 V to 250 V AC, 50 Hz to 60 Hz, 3 A max, Output 12 V DC. 35 W |
| Data Storage | 100,000 groups of curves |
| Interface | USB A Type × 1, Micro-USB × 1, SD card |
| Working Temp | 14 ℉ to 122 ℉ (-10 ℃ to +50 ℃) |
| Storage Temp | -4 ℉ to 176 ℉ (-20 ℃ to +80 ℃) |
| Humidity | ≤95% (non-condensation) |
| Dimension | 6.88 in x 4.13 in x 1.77 in (175 mm x 105 mm x 45 mm) or 1.23 lb (0.56 kg) |
