Overview
Specimen Track network switch wi-fi is a newly developed standard gigabit access switch that can provide full gigabit electrical or optical access and fixed gigabit uplink ports. The Cloud Engine switch is a new generation of gigabit access switch, based on a unified VRP software platform, with enhanced three-layer features, simple operation and maintenance, intelligent stack stacking, flexible Ethernet networking, mature IPv6 features, and other characteristics. It is widely used in various industries such as healthcare, retail, mining, and the Internet.
Features
- Intelligent Stacking
- Minimalist network operation and maintenance
- Integrated security capabilities
Technical Specifications
| Forwarding Performance | 166 Mpps |
| Switching Capacity | 672 Gbps or 6.72 Tbps |
| Fixed Ports | 48 Gigabit SFPs, 4 10 Gigabit SFPs+ |
| PoE+ | Unsupported |
| MAC Features | MAC address auto-learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting |
| VLAN Features | 4094 VLANs Guest VLAN, Voice VLAN GVRP MUX VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping |
| IP Routing | Static route, RIPv1/v2, RPing, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+ |
| Super Virtual Fabric (SVF) | Plug-and-play SVF clients Automatic software package and patch loading to SVF clients One-click and automatic delivery of service configurations Independent SVF client operation |
| Interoperability | VBST (compatible with PVST/PVST+/RPVST) LNP (like DTP) VCMP (like VTP) |
| Dimension | 17.40 in x 16.54 in x 1.72 in (442 mm x 420 mm x 43.6 mm) |
