Overview
GAOTek Resistive Touch Screen Industrial Panels were made of brushed aluminum in beautiful shape, no cable is good at shockproof, and high performance at low power consumption, can be used in hard environment. It supports wireless 3G or WIFI, With the shockproof, moisture-proof, waterproof and dustproof (meet the NEMA IP 65 standard), high temperature resistant, multi-slot and easy to expand characteristics, so it is widely used in industrial control, vehicle control, environmental control, Miliary control, Monitoring system, Network security, Digital signage, Date storage and other automation applications.
Technical Specifications
| dimension | 11.22 in x 7.59 in x 1.61 in (285 mm x 193 mm x 41mm) |
| screen size | AUO 10.1 in (25.65 cm) |
| Display area | 8.34 in x 5.90 in (212 mm x 150 mm) |
| Resolution | 1024 pixels x 600 pixels |
| Contrast | 700:1 Type |
| Screen colors | 262 K or 16.2 M 6-bit or 6-bit + FRC |
| Display brightness | 450 cd/m2 |
| Touch panel | AMT Touch panel of resistance |
| Chipset | Intel Atom D2550+ NM10 |
| CPU | Intel ATOM D2550 1.86 G |
| RAM | DDR3 2 Gb ram, MAX 4 Gb |
| SSD | SSD 64 GB, option 128 GB, 256 GB |
| System | Windows XP or win 7, xp , Linux |
| LAN | 2*RJ45, Intel RTL8111C 1000Mbps |
| USB 2.0 | 4 |
| COM(COM) | 2*RS232 |
| VGA | 1 |
| HDMI | 1 |
| LPT | 1(optional) |
| Microphone Input/output | 1(optional) |
| Wireless 3G/WIFI | 1(optional) |
| Operating Humidity | 5% to 85% (non-Condensing) |
| Operating Temp | -40 °F to 176 ° F (-40 °C to +80 °C) |
| Storage Temp | -22 °F to 158 ° F (-30 °C to +70°C) |
| Color | Black |
| Power | 110 V to 240 V AC |
| Power adapter | 12 V to 5 A DC |
| Weight | 7.71 lb (3.5 kg/set) |
