Overview
Specimen Track RFID Reader & Writer Module is a contactless smart card reading and writing module developed based on ISO/IEC14443 -1, -2, -3, -4 and ISO15693 international standard protocols. It adopts highly integrated special card reading chip, advanced watchdog and voltage monitoring circuit project design and features a high degree of integration, strong anti-interference ability, small size and more stable performance.
Technical Specifications
| Frequency | 13.56Mhz |
| Protocol | ISO/IEC 14443-A/B, ISO/IEC 15693 |
| Read-Write Chip | MFRC500, MFRC400,MFRC632 |
| Interface | TTL, RS232, RS485 (customize USB, ABA) |
| Baud Rate | 9600-115200bit/s |
| Supporting Card | HF chips |
| Antenna | External |
| Application | Identification |
| Dimension | 1.54 in x 0.35 in x 0.35 in (39mm X 9mm X 9mm) |
