Features
- Input or output AES or EBU, AES3, and S or PDIF compatibility
- Built-in auto synchronization, no need for manual setup
- Supports point-to-point and point-to-multipoint configurations
- Easy plug-and-play installation for user convenience
- LED indication for status monitoring
- Optional optical transmission at 1310 nm, 1550 nm, CWDM, or DWDM.
Technical Specifications
| Input Channels | 1-16 unidirectional |
| Input Level | 0.2 to 7.0 VP-P |
| Input Sampling Rate | 32 KHz to 108 KHz |
| Input Impedance | 110 ohm (balanced) 75 ohm (non-balanced, optional) |
| Connector | XLR, BNC |
| Output Channel | 1-16 unidirectional |
| Output Level | 5 VP-P |
| Output Sampling Rate | 48 KHz (other optional) |
| Jitter | <0.005 UI P-P |
| Rise/Fall Time | <25 ns |
| Output Impedance | 110 ohm (balanced) 75 ohm (non-balanced, optional) |
| Connector | XLR, BNC |
| Wavelength | 1310 nm (1550 nm, CWDM optional) |
| Transmitter Optical Power | -10 dBm ± 2 dBm (-0 dBm ± 3 dBm optional) Receiver Optical Power -28 dBm to -3 dBm |
| Distance | 0 mi (0 Km) to 12.427 mi (20 Km) (longer optional) |
| Connector | FC PC (optional FC or APC, SC or PC, SC/APC) |
| Power Supply | AC Voltage AC 220 V |
| Power Consumption | AC 220 V, <20 W |
| Dimensions | 19 in (48.26 cm)1U or 2U rack mount 17.0 in x 9.1 in x 1.7 in (430 mm x 230 mm x 43 mm) |
| Receiver optical power | -28 dBm to -3 dBm |
| Channels | 4 Channels |
