| Network |
Wi-Fi |
| Switching Capacity |
368 Gbit or s |
| Forwarding Performance |
276 Mpps |
| Maximum Board Capability |
Fixed-configuration router |
| Power Module |
2, 1+1 |
| Capacity Density (G/U) |
184 |
| CPU |
8-core 1.5 GHz |
| SDRAM |
4 GB x 1 |
| Flash memory |
64 MB |
| Storage |
8 GB |
| Maximum number of 100GE ports |
0 |
| Maximum number of 50GE ports |
2 |
| Maximum number of 25GE ports |
2 |
| Maximum number of 10GE ports |
16 |
| Maximum number of GE ports |
30 |
| Maximum number of FE ports |
30 |
| Maximum number of electrical ports |
4 |
| Redundant power supply |
1+1 |
| Maximum input cable size [mm²] |
4 mm² |
| Power supply mode |
AC or HVDC built-in |
| Rated input voltage |
200 V to 240 V or 100 V to 127 V or – 48V to – 60V dual-live wire, supporting 240 V HVDC |
| Input voltage range |
100 V to 240 V or – 40 V to – 72 V |
| Maximum input current |
10A or 4 A |
| Front-end circuit breaker/fuse |
≥4A |
| Switching capacity |
368 Gbit or s (Bidirectional) |
| Maximum number of physical ports on the entire device |
32 |
| Long-term operating temperature |
-40 °F to +149 °F (-40 °C to +65 °C) |
| Restriction on the operating temperature variation rate |
≤ 30° C or hour (54°F or hour) |
| Storage temperature |
-40 °C to +70 °C (-40 °F to +158 °F) |
| Long-term operating relative humidity |
5% RH to 95% RH, non-condensing |
| Storage relative humidity |
5% RH to 100% RH, non-condensing |
| Storage altitude |
16404 ft (< 5000 m) |
| Dimensions (H x W x D) |
1.75 in x 17.40 in x 8.66 in (4.45 cm x 44.2 cm x 22.0 cm) |
| Weight |
9.04 Ibs (4.1 kg) |
