Technical Specifications
| Range | 5 N,10 N,20 N,50 N,100 N N,200 N,500 N,1000 N |
| Input resistance | 385 ± 35 Ω |
| Output Impedance | 350 ± 3 Ω |
| Insulation resistance | ≥ 2000 MΩ |
| Caliber | DN 15 to DN (600 cm) |
| Sensitivity | 1.5 ± 0.1 mv / V |
| Comprehensive accuracy | 0.05 %FS |
| Creep | ± 0.03 %FS/30 min |
| Lag error | ± 0.03 %FS |
| Allow overload | 120 %FS |
| Repeatability error | ± 0.03 %FS |
| Sealing class | IP66 |
| Allow overload | 120 %FS |
| Material | Aluminum alloy |
| Nonlinear | ± 0.03 %FS |
| Range of working temperature | -4 °F to 158 °F (-20 ℃ to +70 ℃) |
| Excitation voltage | -4 °F to 158 °F (-20 ℃ to +70℃) |
| Zero temperature coefficient | ± 0.02 %FS/18 °F (± 0.02 %FS/10 °C) |
| Output temperature coefficient | ± 0.02 %FS/18 °F (± 0.02 %FS/10 °C) |
| Cable | Φ0.2 in x 78.7 in (Φ 0.5 cm x 200 cm) |
