Features
- Remote digital reading system.
- Prepaid water usage control.
- Long-range IoT connectivity.
- Ultra-low power consumption.
- Durable IP68 waterproof design.
Technical Specifications
| Nominal Diameter | DN 40 and DN 50 and DN 65 |
| Communication | Long Range Remote Reading Via Iot |
| Control Method | Remote Valve Control |
| Application | Residential or Commercial and Industrial Water Metering |
| Body Material | Brass and Engineering Plastic |
| Protection Level | Ip 68 |
| Display Type | Digital LCD With Backlight |
| Installation Position | Horizontal and Vertical |
| Measurement Standard | ISO 4064 and OIML R 49 |
| Accuracy Class | Class B and Class C |
| Minimum Flow Rate | 0.5 Mh to 1.6 Mh |
| Transitional Flow Rate | 1.2 Mh to 3.2 Mh |
| Nominal Flow Rate | 16 Mh to 40 Mh |
| Pressure Rating | PN 16 and PN 25 |
| Data Transmission | Remote Reading and Prepaid Balance Updates |
| Connectivity | Iot Enabled |
| Power Supply | Built-In Lithium Battery |
| Prepaid Mode | Rechargeable Via Mobile App and Web Portal or Vending Station |
| Valve Control | Remote ON and OFF Control Via Platform |
| Oem Support | Available |
| Compliance | ISO 4064 or MID and OIML R 49 |
| Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Weight | 8.8 Lbs to 17.6 Lbs (4 Kg to 8 Kg) |
| Dimension | 11.8 In X 5.9 In X 7.9 In ( 300 Cm X 150 Cm X 200 Cm) |
