Overview
Versatile ATT Zone Tester with 62.13 mi Range measures the length, loss and connection quality of all kinds of optical fibers and cables, and supports engineering construction, line maintenance and testing, emergency repair, and the development and production of optical fibers and cables.
Technical Specifications
| Wavelength | 1550 nm ± 20 nm, 1310 nm or 1550 nm ± 20 nm |
| Fiber Type | Single mode fiber |
| Event Blind Zone | 8.21 ft (2.5 m) |
| ATT Blind Zone | 26.25 ft (8 m) |
| Measuring Range | 0.31 mi, 0.62 mi, 1.24 mi, 2.48 mi, 4.97 mi, 9.94 mi, 19.88 mi, 39.76 mi, 62.13 mi (500 m, 1 km, 2 km, 4 km, 8 km, 16 km, 32 km, 64 km, 100 km) |
| Pulse Width | 3 ns to 20 us |
| Sampling Resolution | 0.16 ft to 26.25 ft (0.05 m to 8 m) |
| Data Storage | 8 G |
| Laser Safety Grade | Class 2 |
| Frequency Identification | CW or 270 or 330 or 1 k or 2 kHz |
