Technical Specifications
| Applicable Industries | Farms |
| Video Outgoing-Inspection | Provided |
| Machinery Test Report | Provided |
| Core Components | Engine |
| Usage | Agriculture |
| Type | IRRIGATION SYSTEM |
| Material | Plastic |
| Feature | Solar power |
| Application | Agriculture Garden Farm Irrigaiton |
| Battery | 18650 Lithium battery(wide temperature)battery capacity: 2000mAh，four pcs |
| Solar Panel | Polysilicon 6V 5W |
| Advantage | IOT – one valve control two water flow |
| Power Supply | 220V Power supply or 320W solar panel |
| Solar Panel Port | Stable voltage and current device inside,can connect 5V-30V DC power |
| Flowmeter （External） | Max flow rate：10m/s Min flow rate：0.3m/s Working pressure：5kg/cm^2 |
| Valve Torque | ≤60N.m |
| Max Power | 3.8W At communication（Max power at full emission） 25W At locked motor（overcurrent protection inside device） |
| Protection Level | IP67 |
| Control Mode | 4G or LoRawan |
| Global Frequency | LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66 |
| Remote Upgrade | OTA |
| Valve Open Adjustment | Ratio Adjustment |
| Solar Panel Size | 7.68in×7.68in (19.5 cm x 19.5cm) |
| Diameter | 31.50in (80 cm) |
| Weight | 17.64lbs (8 kg) |
