| Material |
ASA |
| Power Supply |
DC 9 to 24 V |
| Wind Speed |
0 to 40 m/s |
| Ingress Protection |
IP65 |
| Output |
RS485 (Modbus) |
| Power Consumption |
<1 W @ 12 V |
| Color |
White |
| MOQ |
1 SET |
| Atmospheric Temperature Range |
(-40 ℃ to 85 ℃) -40 °F to 185 °F |
| Atmospheric Temperature Resolution |
(0.1 ℃) 32.18 °F |
| Atmospheric Temperature Accuracy |
±0.54 °F (±0.3 ℃) (@25 ℃) 77 °F |
| Atmospheric Humidity Range |
0-100% RH |
| Atmospheric Humidity Resolution |
0.01% RH |
| Atmospheric Humidity Accuracy |
±3% RH (10%-80% RH, No Condensation) |
| Atmospheric Pressure Range |
500 to 1100 hpa |
| Atmospheric Pressure Resolution |
0.1 hpa |
| Atmospheric Pressure Accuracy |
±0.5 hpa (25℃, 950 to 1100 hpa) |
| Wind Speed Type |
Ultrasonic |
| Wind Speed Range |
(0 to 40 m/s) 0-131.23 ft/s |
| Wind Speed Resolution |
(0.01 m/s) 0.0328 ft/s |
| Wind Speed Accuracy |
± (0.5 + 0.05 V) m/s |
| Wind Direction Type |
Ultrasonic |
| Wind Direction Range |
0 to 359.9° |
| Wind Direction Resolution |
0.1° |
| Wind Direction Accuracy |
±5° (When Wind Speed < 10 m/s) |
| Rainfall Type |
Optical |
| Rainfall Range |
0 to 7.87 in/h (0 to 20 cm/h) |
| Rainfall Resolution |
0.00787 in (0.02 cm) |
| Supply |
DC 9 to 24 V |
| Operating Temperature |
-22 °F to 158 °F (-30 ℃ to 70℃) |
| Output |
RS485 Interface (Modbus RTU) |
| Customization Option |
SDI-12 (Extra Cost Applies) |
| Maximum Output Frequency |
Passive Mode: 1/S, Active Mode: 1/min |
| Fixed Form |
A) Sleeve fixed; B) Flange Adapter Fixed |
| Fixed Trestle |
Optional: 4.92 ft (1.5 m), or5.91 ft (1.8 m) Bracket (Extra Cost) |
| Cable |
9.84 ft (3 m) Cable (Optional: 32.81 feet (10 m) Cable for Extra Cost) |
| Ingress Protection |
IP65 |
| Main Material |
ABS Plastic |
| Size |
4.57 in x 10.24 in (11.6 cm x 26 cm) |
