Technical Specifications
| Load Range | 10 t, 20 t, 30 t, 40 t |
| Precision | C3 |
| Comprehensive error | ± 0.02 % FS |
| Creep | ± 0.016 % FS / 30 MIN |
| Input resistance | 750 ± 5 Ω |
| Output resistance | 750 ± 5 Ω |
| Insulation resistance | ≥ 5000 MΩ（100 V DC) |
| Rate output | 2.0 ± 0.002 mv / v |
| Safe overload | 150 % |
| Ultimate overload | 200 % |
| Defend grade | IP68 |
| Temp effect on zero | ± 0.019 % FS / 50 °F (10 ℃) |
| Temp effect on span | ± 0.011 % FS / 50 °F (10 ℃) |
