Features
- Innovative CPU+NP Heterogeneous Forwarding Architecture for superior L3–L7 service processing.
- High SD-WAN Performance exceeding industry standards with optimized forwarding capabilities.
- Comprehensive Application Integration including SD-WAN, cloud management, routing, and more.
- Intelligent Traffic Steering and optimization based on application SLA, priority, and bandwidth.
- Bandwidth Utilization Enhancement up to 90% for improved performance.
- SD-WAN Ready with plug-and-play functionality for easy setup.
- Automated Network Provisioning via email, USB flash drive, or DHCP.
- Centralized O&M Tools
Technical Specifications
| Network | Wireless Lan, Wired LAN |
| Memory | 2 GB |
| Wi-Fi | Dual Band (2.4 GHz And 5 GHz), 802.11b Or g Or n Or ac |
| DSP (Voice) | Built-In 64-Channel Voice |
| SIC Slots | 2 |
| CPU | 1.4 GHz, 4 Cores |
| Flash Memory | 1 GB or 512 MB |
| Fixed LAN Ports | 8 x GE RJ45 (Can Be Configured As WAN) |
| Fixed WAN Ports | 1 x GE combo, 1 x GE RJ45, and 1 x 10 GE SFP+ (Compatible With GE SFP) |
| IPsec Performance (IMIX) | 2 Gbit Or s |
| Console Port | RJ45 |
| Maximum Power Consumption | 30 W |
| Maximum PoE Output Power | 100 W |
| Extended Slots (Standard Configuration) | 2 x SIC |
| Power Supply Mode | AC Built-In |
| Heat Dissipation Mode | Air Cooling |
| Number Of Power Modules | 1 |
| Rated Input Voltage | 100 V To 240 V, 50 Hz/60 Hz |
| Input Voltage Range | 90 V To 264 V, 47 Hz To 63 Hz |
| Maximum Input Current | 2 A |
| Maximum Output Power | 60 W |
| Type Of Fans | Built-In |
| Long-Term Operating Temperature | 32 °F To 113 °F (0 °C to 45 °C) |
| Dimensions Without Packaging (H x W x D) | 1.75 in x 15.35 in x 9.06 in (4.44 cm x 39.0 cm x 22.98 cm) |
| Weight Without Packaging | 6.39 lb (2.9 kg) |
