Technical Specifications
| Ions Type | F-, Cl-, Ca2+, NO3-, NH4+, K+, Hardness, etc. |
| Range | 0 ppm to 5000 ppm |
| Resolution | 0.01 mg/L |
| Voltage or Power | 5.5 V DC to 28 V DC or ≤0.6 W |
| Slope | 52 mV to 59 mV/22 to 29 |
| Accuracy | <±2 % |
| Response Time | <60 seconds (90 % right value) |
| Communication | Standard RS485 Modbus |
| Temperature Compensation | PT1000 |
| Dimension | Diameter: 1.18 in (30 mm), Length: 9.84 in (250 mm), Cable Length: 16.4 ft (5 m, extendable) |
| Working Environment | 32 °F to 104 °F (0°C to 40°C), 0 psi to 29 psi (0 bar to 2 bar) |
| Communication Interface | RS485, Standard Modbus RTU Protocol (Optional: Analog Signal 4 mA to 20 mA) |
| Weight | About 7.76 oz (220 g, without thread) |
