Technical Specifications
| Sensor | Electrochemistry |
| Measure Range | 0 ppm to 5 ppm, 0 ppm to 20 ppm, 0 ppm to 50 ppm, 0 ppm to 100 ppm, 0 ppm to 500 ppm, 0 ppm to 1000 ppm, 0 ppm to 2000 ppm, 0 ppm to 3000 ppm |
| Resolution | 0.001 ppm, 0.01 ppm, 0.1 ppm, 1 ppm |
| Install Method | Wall-mounted, piping type, flow-type |
| Power | 24 V DC |
| Precision | ≤± 2% Full Scale (F.S.) |
| Signal Output | 4 mA to 20mA, 0 V to 5V, RS485, RS232, Relay, Wireless Digital (Optional) |
| Response Time | ≤10 seconds |
| Recovery Time | ≤10 seconds |
| Repeatability | ≤±1 % |
| Linearity Error | ≤±1 % |
| Zero Shift | ≤±1 % (F.S. per year) |
| Display | High Light Nixie Tube Display |
| Connection Mode | G1/2 External Thread Explosion-Proof, Flexible Pipe |
| Unit | ppm, mg/m³ |
| Temperature | -4 °F to 122 °F (-20°C to 50°C) |
| Humidity | 0 % to 90 % Relative Humidity (RH) |
| Explosion-Proof | II 2G Ex db IIC T6 Gb IP65 |
| Degree of Protection | IP65 |
| Power | 12 V to 36 V DC |
| Operating Time | 24 hours |
| Dimensions | 7.09 in × 5.91 in × 3.54 in (180 mm × 150 mm × 90 mm) |
| Weight | ≤3.53 lbs (1.6 kg) |
