Technical Specifications
| System | GPS+BEIDOU+GLONASS |
| Chipset | AT6558R |
| Receiver | 32 Channel |
| Cold Start | ≤ 32 s |
| Hot Start | ≤ 1 s |
| Cold Start Capture Sensitivity | -148 dBm |
| Tracking Sensitivity | -165 dBm |
| Accuracy | <2.5 m（CEP50） |
| Bands | -CN LTE FDD：Band 1,3,5,8 LTE TDD：Band 34,38,39,40,41 WCDMA: Band 1,5,8 GSM/EDGE: Band 3,8(Optional)-EU LTE FDD：Band 1,3,5,7,8,20,28 LTE TDD：Band 38,40,41 WCDMA: Band 1,5,8 GSM：Band 3,8-AU LTE FDD：Band 1,2,3,4,5,7,8,28,66 LTE TDD：Band40 WCDMA: Band 1,2,4,5,8 GSM/EDGE：Band 2,3,5,8 |
| Size | 7.68 in x 4.49 in x 1.46 in (195 mm x 114 mm x 37 mm) |
| Weight | 29.38 oz (833 g) include main unit and hard lock hock soft rope |
| Material | Engineering plastic |
| GPS Module | AT6558R |
| GSM Module | Quectel M25, EC200 series or EC25 series |
| Working Temperature | -4 ° F to 176 °F (-20 °C to 80 °C) |
| Store Temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Humidity | 5% to 99% |
| Built in Battery Capacity | Rechargeable battery 10400 mAh |
| Average Working Current | < 90 mA |
| Average Current Standby | < 100 uA |
| Working Hour | 2G device (10400 mAh) continuous full load operation for 100 hours |
| 3 or 4G device (10400 mAh) normal working mode: 70 hours | |
| Waterproof | IP67 |
| Transmission Mode | Support TCP(GPRS) or SMS (short message) |
| Charging Specification | DC 5V, 2A, 5521 interface |
| Motion Sensor | 3D acceleration sensor |
| Memory | 2 MB |
| Antenna | GSM or GPS default built-in antenna |
| Lock Hook | Stainless steel, tensile resistance 440.93 lb (200 KG) |
| LED | 4 indicators (Communication. Location. Low power. Charge） |
| SIM | Double card single standby, Micro SIM card |
