Features
- Real-time tracking: GPS precise tracking scope 10m, always know where cargos are
- Abnormal alarms: Anti-theft alarm/ drop alarm/ low power alarm/ dismounting alarm
- Long used battery life: can hold 7-90 days after once full-charge
- Wide range of communication device: cell-phone, PC, or tablet
- Multi module communication: UHF, GPRS, GPS, LORA
Technical Specifications
| Parameters | Description |
| Voltage | 800 mAh li po rechargeable battery |
| Indication Interface | 4 LED lights: GPRS, positioning, operation, peripheral |
| IO | RS232 serial port, 6 groups of digital input IO, 2 groups of analog input IO, 2 groups of digital output |
| Current | Average current <100 mA |
| Communication | GPRS communication TCP or IP, built-in GSM antenna |
| Positioning Module | GPS, 2.5 M CEP at -130 dbm (Open Sky), built-in GPS antenna |
| LORA Communication | GSM band 850 MHZ, 900 MHZ, 1800 MHZ, 1900 MHZ |
| Storage | Blind spot save records> 40000, FLASH 64 M bit |
| BT Chipset | BLE4.0 (for parameter configuration, upgrade, etc. management) |
| SIM Card | Dual SIM cards, built-in SIM card and external SIM card |
| LORA | LORA (915 MHZ) external antenna, can work with 12 LORA sub-locks If you need more, you need to modify the current software |
| LORA Distance | 3280.84 ft (>2 km) |
| Alarm | Sub-lock with anti-open alarm, anti-break, anti-cut |
| Material | ABS |
| Temperature | -13 °F to 185 °F (-25 ℃ to 85 ℃) |
| Size | 4.07 in x 2.93 in x 0.89 in (103.5 mm x 74.5 mm x 22.5 mm) |
