Technical Specifications
| Processor | Qualcomm Alder Quad A73 2.2 GHz (IPQ9570 or IPQ9574) |
| Wireless Chipset | Waikiki 2.4 GHz band QCN6224 – 2.4 GHz Waikiki 5 GHz band QCN6274 – 5 GHz
Waikiki 6 GHz band QCN6274 – 6 GHz (EU or US) |
| 2.5ge Phy | Qualcomm QCA8084 |
| 10ge Phy | MARVELL AQR113C (10 GBE) RJ45 ×2 |
| SPI NOR Flash | 16 MB |
| SPI NAND Flash | 256 MB |
| DDR4 | 2 GB (32-bit) |
| Fixed Port | 1 × 10 M or 100 M or 1000 M or 2500 M or 5000 M or 10000 M Base-TX MDI or MDIX RJ-45 port with PoE PD 802.3 bt 4x 2.5 GE LAN
1×1000 M or 2500 M or 10000 M SFP 1x USB 3.0 port 1x Console port 1x DC power jack |
| Wireless | Radio 1 802.11be, 4 x 4 2.4 GHz 1376 Mbps Radio 2 802.11be, 4 x 4 5 GHz 11.5 Gbps
Radio 3 802.11be, 4 x 4 6 GHz 11.5 Gbps |
| Antenna | 8x External dual band antennas –2.4 G or 5 G or 6 G |
| Operating Frequencies | 802.11be or ax or ac or n or a 5150 GHz to 5.850 GHz 802.11 11be or ax or b or g or n 2.4 GHz to 2.483 GHz
802.11be or ax or ac or n or a EU 5.945 GHz to 6.425 GHz US6.115 GHz to 7.125 GHz |
| Supported Standards | IEEE 802.11a or b or g or n or ac or ax or be IEEE 802.11d or e or h or I or j or k or r or u or v or w
IEEE 802.11ba |
| Modulation Mode | Modulation 802.11a/g/n BPSK, QPSK, 16QAM, 64QAM
802.11b CCK (11 & 5.5 Mbps), DQPSK (2Mbps), DBPSK (1Mbps) 802.11n PSK or CCK, DBPSK, DQPSK, OFDM 802.11ac BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11ax BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM |
| Maximum Radio Power | 2.4 GHz 20 dBm 5 GHz 20 dBm
6 GHz 20 dBm (Transmit power is multi-chain combined power, no antenna gains included. The actual transmit power depends on local laws and regulations) |
| Bandwidth | 20 MHz or 40 MHz in 2.4 GHz 20 MHz, 40 MHz, 80 MHz, 160 MHz or 320 MHz to 80 MHz in 5 GHz and 6 GHz |
| Operating Temperature or Storage Temperature | Operating Tem 14 ℉ to 122 ℉ (-10 ºC to 50 ºC) Storage Tem -40 ℉ to 167 ℉ (-40 º C to 75 º C) |
| Power Source | PoE PD 802.3 BT 60 W Adapter 12 V DC 3.5 A |
| Power Consumption | <45 W |
| Dimension | 10.24 in x 6.30 in x 1.77 in (260 mm x 160 mm x 45 mm) |
| Weight | 3.97 lb (1.8 kg) |
