Features
- Robust stainless-steel construction
- Versatile pull pressure and two-way force measurement
- Long 24-month warranty
- Easy screw hole fixed installation
- Designed for durability
Technical Specifications
| Parameter Output -R.O. | 1.0 ± 10 % mV/V |
| Response Frequency | 1 kHz |
| Zero-point Output | + 2 % F.S. |
| Material | Alloy steel |
| Non-Linearity | 1.0 % F.S. |
| Hysteresis | 1.0 % F.S. |
| Repeatability | 1.0 % F.S. |
| Working Power | 5 to 10 V |
| Impedance | 7000 Ω |
| Insulation Resistance | ≥ 5000 M / 100 V DC |
| Creep (30 min) | 0.1 % F.S. |
| Coupling Accuracy | 0.5 % F.S. |
| Safety Overload | 120 % R.C. |
| Extreme Overload | 200 % R.C. |
| Zero Temperature Drift | 0.05 % F.S. / 10 °C |
| Operating Temperature Range | -4 to 176 °F (-20 to 80 °C) |
