Technical Specifications
| Voltage Rating | 3.7 V to 5.2 V |
| Measuring Range | 7.87 to 314.96 in |
| Amplifier Type | VCSEL |
| Voltage Supply | 70 mA |
| Resolution (bits) | 0.393701 in (1 cm) |
| Frequency | 250 Hz |
| Output | 0.35 W |
| Sensing Range | 7.87 to 314.96 in |
| Operating Temperature | 50 °F to 140 °F. (-10 ℃ to 60 ℃) |
| Peak Current | 150 mA |
| Voltage Rating | 3.7 V to 5.2 V |
| Dimension | 1.38 in X 0.84 in X 0.49 in (35 mm X 21.25 mm X 12.5 mm) |
| Weight | 0 17 oz (5 g) |
| Frame Rate | 1 to 250 Hz |
| Ambient Light Immunity | 70 Klux |
| FOV | 2 degrees |
| Power Consumption | <= 0.35 W |
| Distance Resolution | 0.39 in (1 cm) |
