LoRaWAN Low Power Gateway With External Antenna, 4G & Multiple Interfaces – Specimen Track

Name: LoRaWAN Low Power Gateway With External Antenna, 4G & Multiple Interfaces - Specimen Track -
SKU: STRLLPG-103

This 4G LoRaWAN gateway has multiple WAN ports, serial interfaces, an external antenna for enhanced range, and works in wide temperature range.

SKU: STRLLPG-103 Category: LoRaWAN

Technical Specifications

Network Standard	4G
Power Supply	9 to 24 V DC
Support Band	433 or 470 or 868 or 915 or 923 MHz
Antenna	External antenna
Interface	4 WAN, 232 serial port, 485 serial port, USB and 4 AD or IO
Protocol	Standard LoRaWAN protocol
Working Temperature	– 4 °F to 176 °F (- 20 °C to 80 °C)
Dimension	5.79 in x 2.3 in x 5.79 in (14.7 cm x 5.85 cm x 14.7 cm)
Ingress Protection	IP 67 Waterproof
Connectivity	4G Wireless WIFI LoRaWAN
Communication Range	9.32 mi (15 km)
Channels	8
Solar Panel	30 W
Power Consumption	8 W
Operating Temperature	– 22 °F to 158 °F (-30 °C to 70 °C)
Battery Charging Temperature	– 4 °F to 122 °F (-20 °C to 50 °C)
