Features
- Support LoRaWAN protocol Class A
- High reliability and stability
- Ultra wide distance transmission
- Battery life up to 6 years
- Rapid installation and deployment
Technical Specifications
| Customized Support | OEM, ODM | |
| Certification | ISO9001 | |
| Output | RS485 (Modbus/RTU) | |
| Cleaning Method | Automatic cleaning | |
| Power Consumption | 5 W @ 12 V | |
| Power Supply | 12 V DC ±5% | |
| Cable Length | 16.4 ft (5 m), other length can be customized | |
| Dissolved Oxygen Sensor – Measuring Range | 0 mg/L to 20 mg/L | |
| Dissolved Oxygen Sensor – Accuracy | ±0.4 mg/L | |
| Dissolved Oxygen Sensor – Resolution | 0.01 mg/L | |
| Turbidity Sensor – Measuring Range And Accuracy | 0 NTU to 100 NTU, ±3% or ±2 NTU, 0 NTU to 1000 NTU, ±5% or ±3 NTU | |
| Turbidity Sensor – Resolution | 0.1 NTU | |
| Conductivity Sensor – Measuring Range And Resolution | 0 µS/cm to 5000 µS/cm, resolution: 1 µS/cm 0 µS/cm to 200 µS/cm, resolution: 0.1 mS/cm 0 PSU to 70 PSU, resolution: 0.1 PSU | |
| Conductivity Sensor – Accuracy | ±1.5% FS | |
| COD Sensor – Measuring Range | COD | Tubidity |
| 0 mg/L to 200 mg/L equiv. KHP | 0 NTU to 100 NTU | |
| 0 mg/L to 500 mg/L equiv. KHP | 0 NTU to 200 NTU | |
| COD Accuracy | ±5% FS | |
| COD Resolution | 0.1 mg/L | |
| Turbidity Accuracy | ±5% FS | |
| Turbidity Resolution | 0.1 NTU | |
| pH Sensor – Measuring Range | 0 pH to 14 pH | |
| pH Sensor – Accuracy | ±0.1 pH | |
| pH Sensor – Resolution | 0.01 pH | |
| ORP Sensor – Measuring Range | -1500 mV to 1500 mV | |
| ORP Sensor – Accuracy | ±6 mV | |
| ORP Sensor – Resolution | 1 mV | |
| Ammonia Nitrogen Sensor – Measuring Range | 0 mg/L to 100 mg/L or 0 mg/L to 1000 mg/L | |
| Ammonia Nitrogen Sensor – Accuracy | ±10% or ±2 mg/L | |
| Ammonia Nitrogen Sensor – Resolution | 0.1 mg/L | |
| Temperature – Measuring Range | 32 °F to 122 °F (0 °C to 50 °C) | |
| Temperature – Accuracy | ±32.9 °F (±0.5 °C) | |
| Resolution | 32.18 °F (0.1 °C) | |
