Features
- Integrated Power Meter
- Visual Fault Locator
- High-Resolution Display
- User-Friendly Interface
Technical Specifications
| Type | OTDR |
| Network | Wireless LAN, SDK, TCP/IP, POE, GPRS, Wi-Fi, GSM, 3G |
| Event Blind Zone | 6.6 ft (2 m) |
| ATT Blind Zone | 39.4 ft (12 m) |
| Dynamic Range | 22 to 20 dB |
| Display | High-resolution touchscreen |
| Storage Capacity | 4 GB internal, expandable with USB |
| Power Supply | Rechargeable lithium battery |
| Battery Life | 8 to 10 hours continuous operation |
| Charging Time | 2 to 3 hours |
| Supported Languages | English, Spanish, Portuguese, French, Chinese, etc. |
| Type of Connectors | FC/PC, SC/PC (Optional: FC/APC, SC/APC) |
| VFL Output Power | 1 mW |
| OPM Range | -50 to +26 dBm |
| Certifications | CE, RoHS, FCC |
| Humidity | 0% to 95% non-condensing |
| Laser Safety | Class 1 laser product |
| Weight | 3.3 lbs (1.5 kg) |
| Dimensions | 17.7 x 11.8 x 7.9 inches (45 x 30 x 20 cm) |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
