Optical Time Domain Reflectometer Built in Power Meter – Specimen Track

Name: Optical Time Domain Reflectometer Built in Power Meter - Specimen Track -
SKU: STRTDRT-174

High-performance OTDR for FTTx networks with excellent resolution, minimal dead zone, multi-wavelength options, and advanced testing features

SKU: STRTDRT-174 Category: Ethernet

Features

Display	5.8 in color TFT-LCD touch screen
Battery	7.4 V / 5000 mAh Li-ion battery, up to 12 hours
Dynamic Range	30 to 35 dB
Event Dead Zone	2.62 ft (0.8 m)
Attenuation Dead Zone	19.69 ft (6 m)
Highest Range Resolution	0.16 ft (0.05 m)
Test Range	0.25 to 317 miles (0.4 to 512 km)
Test Pulse Width	5 to 20,000 ns
Loss Threshold	0.01 dB
Sampling Points	128k
Linearity	0.05 dB/dB
Loss Resolution	0.001 dB
Waveform Storage Capacity	≥1000 waveforms
Operating Temperature	23 °F to 122 °F (-5 °C to 50 °C)
Storage Temperature	-4 °F to 158 °F (-20 °C to 70 °C)
Relative Humidity	0 to 95% (No condensation)
Dimension	8.46 in x 5.91 in x 2.76 in (21.5 cm x 15 cm x 7 cm)
Weight	<3.31 lbs (<1.5 kg)
