Features
- Supports 1 wired WAN port, switchable LAN port
- Support LoRaWAN gateway
- Support LED status monitoring (display power PWR, LINK, ETH, WLAN, LoRaRX, LoRaTX)
- Support Web platform management and configuration method
- Restore factory settings with one click
- Wired network ports all support 10/100Mbps rate
- Support wired and wireless simultaneous online and multi-network intelligent switching
- Support firmware upgrade and firmware configuration backup function
- Firewall, NAT, DMZ host, access control black- and whitelist, IP speed limit
- QoS and traffic services can limit the speed according to the interface
- Support VPN client
- Supports load balancing multi-network port flow control settings, with network port priority, enablement, flow control ratio, and other working modes
Technical Specifications
| Operating Voltage | 8 V to 28 V |
| Operating Humidity | 5% to 95% |
| Frequency | 868 mhz to 915 mhz |
| Transmit Power | 27dBm |
| Wireless Parameters | |
| TDD–LTE | Downlink rate 130Mbps, uplink rate 35Mbps |
| FDD–LTE | Downlink rate 150Mbps, uplink rate 50Mbps |
| WCDMA | Downlink rate 384kbps, uplink rate 384kbps |
| DC–HSDPA | Downlink rate 42Mbps |
| HSUPA | Uplink rate 5.76Mbps |
| GPRS | Downlink rate 107kbps, uplink rate 85.6kbps |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Dimensions | 4.57 in x 4.13 in x 1.61 in (11.6 cm x 10.5 cm x 4.1 cm) |
| Weight | 14.70 oz (417 g) |
