Technical Specifications
| Type | Infrared (IR) Gas Detector |
| Customized Support | OEM, ODM |
| Material | ABS + LCD |
| Power | Electronic |
| Usage | Household |
| CO2 Sensor Type | NDIR |
| Sensor Lifetime | >10 years |
| Resolution | 1 PPM |
| Input Voltage | DC 6V to DC 36V |
| Power Supply | POE or DC12V adapter (US/EU/EPS) |
| Display | 2.8-inch TFT |
| Green light bar | 0 PPM to 499 PPM |
| Yellow light bar | 500 to 999 PPM |
| Orange light bar | 1000 to 1499 PPM |
| Red bar | Over 1500 PPM |
| Sensors | NDIR CO2 sensor, temperature, and humidity sensor |
| Signal Output | RS485 and relay data logger support |
| CO2 | 400–5000 PPM, ±1 PPM |
| Temperature | -4°F to 140°F (-20°C to 60°C), ±2°C (±3.6°F) |
| Humidity | 5% to 95% RH, ±5% RH |
| Operating Temperature | 32°F to 122°F (0°C to 50°C) |
| Operating Humidity | 0% to 95% RH (non-condensing) |
| Product Dimensions | 3.4 in x 3.4 in x 1.7 in (8.6 cm x 8.6 cm x 4.2 cm) |
| Weight | 17.6 oz (500 g) |
