Features
- Multifunctional Design
- Dual Wavelength Support
- Long Testing Range
- High Precision Measurement
Technical Specifications
| Application | FTTH, FTTB, FTTX Solutions |
| Fiber Type | 9/125µm Single-Mode Fiber |
| Data Storage | Internal: >600 traces; External: TF card |
| File Format | Standard SOR |
| Display | 3.5-inch color LCD |
| Data Interface | Micro USB |
| External Storage | TF Card |
| Power Supply | 3.7V, 4000mAh Lithium Polymer Battery; Adapter: 5V, 2A |
| Dynamic Range | 24dB (1310nm) / 22dB (1550nm) |
| Event Dead Zone | 9.8 feet (3 meters) |
| Attenuation Dead Zone | 26.2 feet (8 meters) |
| Testing Range | 1,640 feet to 39.7 miles (500 meters to 64 kilometers) |
| Pulse Width | 3ns to 10µs |
| Loss Accuracy | 0.05dB/dB |
| Sampling Points | 16k to 128k |
| Sampling Resolution | 0.16 feet to 26.2 feet (0.05 meters to 8 meters) |
| Reflection Accuracy | ±3dB |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Weight | <0.77 pounds (<350 grams) |
