Features
- Touchscreen interface
- Integrated fault locator
- Built-in power meter
- Supports various wavelengths
Technical Specifications
| Usage | FTTH (Fiber to the Home) |
| Data Storage | Internal: ≥3000 results, External: 4GB |
| Interface Type | FC/PC (Interchangeable with SC, ST) |
| Connector | Universal FC/SC/ST |
| Display | 5.8-inch color LCD with touchscreen |
| Battery Working Hours | >10 hours |
| Reflection Accuracy | ±3 dB |
| Loss Precision | ±0.05 dB |
| Wavelength Range | 800 nm to 1700 nm |
| Calibration Wavelengths | 850 nm, 980 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm (in cm) |
| Test Scope | -50 dBm to +26 dBm |
| Relative Humidity | 0% to 95% (non-condensing) |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Dimensions | 8.9 in x 6.3 in x 2.8 in (22.7 cm x 16 cm x 7 cm) |
| Weight | 2.6 lbs (1.2 kg) |
