Overview
Specimen Track industrial 4-port POE ethernet switch is an industrial Ethernet PoE switch with 4 electrical ports and 1 optical port. It supports network management, meets IP 30 protection level and EMC industrial grade requirements, supports triple power input, redundant backup, and greatly improves the reliability of product power supply. Simple management mode, plug and play, no configuration required, easy to use.
Features
- Provides 4 RJ 45 ports, 1 SFP fiber port
- Supports multiple IEEE802.3 standards
- 4 POE ports with 30 W power each
- Supports various MAC address management functions
- Three power inputs for reliable supply
- Supports port-based bandwidth control
- Supports link aggregation up to 4 ports
Technical Specifications
| Power Supply | 44 V DC to 57 V DC / 3 A (MAX) |
| Standards | IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at |
| Input Voltage | 44 V DC to 57 V DC |
| Switching Capacity | 10 Gbps |
| Ports | 4 × 10 / 100 / 1000 Mbps RJ 45 PoE ports + 1 × SFP port |
| Indicators | 4 status indicators Link / ACT, 4 PoE indicators, 1 SFP fiber port indicator (Link), power indicator |
| Forwarding Mode | Store and Forward (Full Wire Speed) |
| PoE port | 4 802.3 at / af standard POE |
| Max / Average Power Port | 30 W per port |
| MAC Address Table | 4 K |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.44 Mpps |
| Installation | DIN rail / wall mount |
| Operating Temperature | -40 ℉ to 167 ℉ (-40 ℃ to 75 ℃) |
| Storage Temperature | -40 ℉ to 185 ℉ (-40 ℃ to 85 ℃) |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
| Weight | 0.66 lb (300 g) |
| Dimensions | 5.35 in x 4.25 in x 1.52 in (136 mm x 108 mm x 38.5 mm) |
