Overview
Specimen Track industrial router with ethernet port is an industrial 5G wireless router that integrates multiple functions such as WIFI transmission, local resource sharing, cellular mobile Internet access, precise GPS positioning, serial port pass-thru transmission, and backend remote management. It provides more processing performance, richer interfaces and higher network connection speed than ordinary industrial routers. This product is suitable for different application types and scenarios, such as car WIFI, video transmission, PLC remote control, smart express cabinet, video surveillance, 5G access application etc.
Features
• 1200 Mbps Dual Band Access Point
• Support 5G Network Access
• Gigabit Network Port Design
• Precise GPS Positioning
• Hardware Watchdog
Technical Specification
| Max. LAN Data Rate | 1300 Mbps |
| With Modem Function | Yes |
| Wi-Fi Supported Frequency | 2.4G and 5G |
| 2.4G Wi-Fi Transmission Rate | 300 Mbps |
| Standards And Protocols | Wi-Fi1.77lb(802.11 g),Wi-Fi802.11b,Wi-Fi802.11n,Wi-Fi802.11ac,Wi-Fi802.11a |
| Encryption Type | WPA2-PSK, WPA2, WPA3, WPA-PSK, WPA, WEP |
| LAN Ports | 4 x10 Mbps or 100 Mbps or 1000 Mbps |
| Supports WDS | No |
| Supports WPS | No |
| Wi-Fi Transmission Standard | 802.11 ac |
| Wired Transfer Rate | 10 Mbps or 100 Mbps or 1000 Mbps |
| Private Mold | Yes |
| WAN Ports | 1 x10 Mbps or 100 Mbps or 1000Mbps |
| 5G Wi-Fi Transmission Rate | 867 Mbps |
| 5G | 5G LTE Cat4 Modem |
| SIM Card Slot | Dual SIM Card Slot, Push-Push Type |
| Wi-Fi Standard | 802.11 a or b or g or n or ac |
| Wi-Fi | Dual Band WIFI 2.4 GHz and 5 GHz |
| Wi-Fi Speed | 1300 Mbps |
| USB | 1 x USB 3.0 Port |
| Enclosure | Metal Casing |
| CPU | MTK7621 |
| Flash | 128 Mbit |
| RAM | DDR2 1 Gbit |
| WAN | 1 x 10 M or 100 M or 1000 M Ethernet Port, AutoMDI or MDIX, Built-in 1.5 KV Electromagnetic Isolation Protection |
| LAN | 4 x 10 M or 100 M or 1000 M Ethernet Port, Auto MDI or MDIX, Built-in 1.5 KV Electromagnetic Isolation Protection |
| SIM Card | 2 x Push-Push SIM card Slot |
| USB | 1 x USB 3.0 Port |
| UART | 1 x RS232 or RS485 Serial Communication |
| Power | 1 x Standard DC Connector, Built-in Power Reverse Protection |
| Antenna | 4 G x 5 G Antenna, 2 GHz x 2.4 GHz Wi-Fi Antenna,x GPS Antenna(optional) |
| LED Indicators | 1 x SYS System Status Indicator, 4 x LAN EthernetStatus indicator, 1 x WAN Ethernet StatusIndicator, 2 x WIFI Status Indicator, 1 x NET Internet Indicator, 1 x GPS Status Indicator |
| Reset | 1 x Pinhole Reset Button |
| Input Power | DC 12 V or 1.5 A |
| Power Range | DC 9 to 30 V |
| Power Consumption | <2 A (12 V) |
| Dimensions | 7.8 in x 5.5 in x 1.1 in (200 mm x 141 mm x 28 mm) |
| Weight | 2 lb (920 g) |
