Overview
This POE Control System has a 48K sampling rate, AoIP 6.35 balanced output audio output mode and 20 Hz to 20 kHz frequency response.
Technical Specifications
| Power input | POE+, DC24V150W |
| Audio output mode | AoIP 6.35 balanced output |
| Mic Input | RJ45 |
| Connection | hand-held, support ring connection |
| Control (RJ45) | TCP or IP |
| Static power consumption | external power supply 4W, POE power supply 8W. |
| Frequency response | 20Hz to 20kHz |
| Wall control screen interface | voltage 24 V, distance≦100M |
| POE | 10 BASE-T: Category 3, 4, 5 unshielded twisted pair (≤100m). 100BASE-TX: Category 5 and above unshielded twisted pair (≤100m). |
| Speed | 100M or 1000M bps |
| Sampling rate | 48 K |
| Heat dissipation | Natural convection heat dissipation |
| Signal-to-noise ratio (S or N) | >80 dB |
| Harmonic distortion | <0.5% |
| Weight | 2.4 lb (1 Kg) |
