Features
- IP68 waterproof for robust outdoor use
- Non-rechargeable battery with up to 10 years of life
- Supports CatM1, NB-IoT, and fallback to 2G GSM
- Equipped with Bluetooth beacon and BLE sensor compatibility
- Strong magnetic mount with secure installation
- Theft recovery and motion sensor
- Jamming detection for enhanced security
- Accurate GPS with error margin less than 10m
Technical Specifications
| Parameters | Description |
| Communication Module | Quectel BG96 |
| Cellular | Cat-M1, NB-IoT, fallback to 2G GSM |
| Frequency Bands | FDD LTE: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B28 |
| GPS Sensitivity | -147 dBm |
| Position Accuracy | 8.2 ft (2.5 m) |
| Accelerometer | 3-axis G-sensor |
| Wi-Fi Positioning | Wi-Fi 2.4 GHz |
| Bluetooth | BLE 4.2 |
| Battery | Non-rechargeable lithium-ion, 20000mAh |
| Battery Life | Up to 10 years |
| GNSS Antenna | Internal High Gain |
| Cellular Antenna | Internal High Gain |
| Indicator Lights | 2 LEDs (Blue for GPS, Red for Cell/GSM) |
| Water Resistance | IP68 |
| Operating Temperature | -4 °F to 131 °F (-20 °C to 55 °C) |
| Dimension | 6.06 in x 3.23 in x 1.54 in (15.4 cm x 8.2 cm x 3.9 cm) |
| Weight | 10.76 oz (305 g) |
