Features
- Real time 4G and SMS data upload with GPS
- Integrated 16-bit MCU and siemens 4G and ethernet module
- Programmable data input type and alert hi or low
- Programmable data upload interval and logging interval
- Easu setup via USB port by PC software
- Remote setup over 4G mobile network
- RS485 port support data capturing in Modbus protocol
- Support dynamic domain name or fixed IP, and UDP or TCP protocol data transmission
- Flexible AC or DC power with internal battery backup
Technical Specifications
| Pulse Channel | On and Off Switching |
| Industrial Protocol | Modbus |
| Digital Channel | Alarm Dry Contact |
| Alarm Trigger | Digital Alarm, AD Level High or Low and Power Loss |
| Temperature Sensors | 2 Temperature Sensors (max.) |
| Humidity Sensor | 1 Humidity Sensor |
| Analog Channels | 8 Analog Channels (max.) |
| Digital Input | 10 Digital Inputs |
| Pulse Channel | 4 Pulse Channels |
| Relay Output | 4 Relay Outputs |
| Power Input | 9 V to 15 V; DC |
| Display Type | Analog and digital |
| Signal Type | 4 mA to 20 mA or 0 V to 5 V; DC |
| Output | 5 V; DC |
| Modbus Device Port | RS485 and RS232 |
| Data Upload Interval | Programmable (1 min to 24 hours) |
| Battery Life | 24 hours to 48 hours |
| Communication | Ethernet |
| Humidity Range | 1 % RH to 100 % RH (+ or – 1 %) |
| Operating Temperature | -67 °F to 257 °F (-55 °C to 125 °C) |
